Multiple operating modes, off-grid and UPS, MPPT charger built-in.
Compatible with almost all 48V LiFePO4 battery pack.
Integrated smart APP, can remotely diagnose and update.
Max. 6pcs in parallel (Only OH5000TL).
Suitable for customizing various PV Energy Storage System.
Automatic activation of LiFePO4 battery pack.
Rated Power (W): 3600
Nominal Battery Voltage (V): 24
Start-up Voltage (V): 30
Number of MPP Trackers: 1
Nominal Output Current (A): 13.6
Max. Efficiency: 93.5%
Dimensions (W × H × D mm): 300 x 485 x 120
Weight (kg): 8.8±0.5
Protection Level: IP20
Rated Power (W): 5000
Nominal Battery Voltage (V): 48
Start-up Voltage (V): 150
Number of MPP Trackers: 1
Nominal Output Current (A): 21.7
Max. Efficiency: 93.6%
Dimensions (W × H × D mm): 300 x 485 x 120
Weight (kg): 9.5±0.5
Protection Level: IP20
Rated Output Power: 5500W
Max. Peak Power: 11000W
Max. PV Open Circuit Voltage: 500Vdc
MPPT Voltage Range: 120~430Vdc
Rated Battery Voltage: 48
Start-up Voltage (V): 150
MPPT Number: 1
Dimensions (W × H × D mm): 300 x 485 x 120
Weight (kg): 9.5kg
Protection Level: IP20
