Model | T5K | T10K | |
Capacity(W) | 5000W | 10000W | |
DC voltage(V) | 96v/120v/192V | 120v/192v/240V | |
Input voltage(V) | 160-265VAC | ||
Input frequency | 45-65HZ | ||
Output voltage | Four steps AVR, 380V/415V/440V for optional | ||
Output wave form | Pure sine wave | ||
THD | ≤ 3% linear load | ||
Battery DC voltage | 96v/120v/192V | 120v/192v/240V | |
efficiency（whole unit） | 91 | 92 | |
Battery Max charge current | 6-30A adjustable | 30-40A | |
product size(mm) | 700*364*969 | 730*456*1165 | |
running temperature | 0-40 degree celsius | ||
Protections | Protection against short-circuit, over load, high-voltage, reverse polarity protection and low-voltage protection | ||
Over load | 120% of the rate capacity | ||
Short circuit | 300% of the rate capacity | ||
1.with AC reacto(protect against city power current shock)
2.Double Protection(Two fuses,including the city power security and battery power security)
3.Thyristorcharging (40-50a)
4.IGBT converter(High 95% transfer efficiency)
5.AC filter capacitor.
6.IGBT brand(Mitsubishi)
7.SCR brand(
8.All inverter with IOT,get life-long maintenance.
9.we have live stream every week,welcome to test the working performance of the inverter online and experience the use effect
30KW-200KW if for commercial building use，
to provide 24-hour uninterrupted power supply, so that the shopping mall can maintain sufficient power.
