Applications
IDC room, Large and medium computer networks, Banks, Securities, Communication centers, Semiconductor production lines, Large-scale automated production and control systems, Large gymnasium, Conference rooms, Theaters, Highways, Railways, Tunnels and lighting systems.
Introduction
Digital UPS is our latest models.It's the collection digitization,informationization,network as one of high intelligent products,with powerful information acquisition system, signal processing system,detection system and perfect protection system.Widely used in all kinds of electricity environment,personalized design, powerful human-machine conversation function.Visual display and state monitoring interface,make each user operate simply and conveniently.
Features
●Support 220/230/240/380/400/415VAC,50/60Hz power system
●Pure online double conversion technology to provide best quality of power supply
●Suitable for all kinds of loads and high overload capacity
●Super wide range of input voltage anti-interference, adapt to harsh environment in power network
●Intelligent battery management, extending the battery life
●Large LCD display with friendly human-machine interface
●High reliability design
Double conversion online design, make output for UPS frequency tracking, phase-locked regulator,filter noise low distortion, without interference of pure sine wave power supply,so that UPS for user provide more comprehensive and perfect protection.With zero output conversion time to meet sophisticated equipment for power high standard requirements.
●Load protection ability
Machine the internal standard matches output isolation transformer, anti-interference ability, environment and working conditions of information,user-friendly operation of the UPS.To provide more comprehensive and perfect protection for users'equipments.Tiny ground zero voltage difference,the power supply to meet the needs of precision instruments to protect the safe operation of equipments.
Excellent load compatibility, can be applicable to various types of loads, to meet various needs of applications.
●Environment adaptable
Wide voltage input range and avoid frequently switching to battery power supply, adapt to the power environment in poor areas.Wide input frequency range of UPS,generators can be guaranteed access to a variety of fuel oil stability.
●Optimization of high performance battery
Using intelligent battery management technology to extend the life of the battery and reduce the number of maintenance.Advanced constant voltage charging technology, maximum activation of the battery, charging time saving, to extend battery life.With LCD display panel,to the user for accurately displaying the working environment and UPS status information, user friendly operation of UPS through RS232 interface and intelligent monitor software to communicate with computer and various parameters of UPS clear displayed on the communications interface.
With SNMP,UPS with remote network management capabilities, providing real-time UPS date and power information through variety of network operating system for communication and management.
Specification
| Model | GS9110C online UPS | GS9310C online UPS | |||||||
| Capacity | 6KVA | 8KVA | 10KVA | 15KVA | 10KVA | 15KVA | 20KVA | 30KVA | 40KVA |
| 6KW | 8KW | 10KW | 15KW | 10KW | 15KW | 20KW | 30KW | 40KW | |
| Input | |||||||||
| Voltage | 220VAC | 380/400/415VAC;3-phase+4wires | |||||||
| Voltage range | ±25% | ||||||||
| Frequency | 50/60HZ | ||||||||
| Frequency range | ±5% | ||||||||
| THDi | <3% | ||||||||
| Power factor | >0.9 | ||||||||
| Bypass voltage | 220VAC±25% | 380/400/415VAC±25%; 3-phase+4wires | |||||||
| Input frequency | 50/60HZ±5% | ||||||||
| Output | |||||||||
| Voltage | 220VAC | ||||||||
| Voltage stability | ±1% stead status | ||||||||
| Frequency | 50/60Hz±0.05Hz | ||||||||
| Power factor | 0.9/1.0 | ||||||||
| Overload | ≤110%for 60 minutes;≤125% for 10min;≤150% for 1min | ||||||||
| Current Crest Ratio | 3:1 | ||||||||
| Transfer time | 0 ms | ||||||||
| Battery | |||||||||
| DC voltage | 192VDC,VRLA,gel,NiCd battery | ||||||||
| Charge time | 8 hours to 90% (it means standard model which battery inside UPS) | ||||||||
| DC ripple voltage | <1% | ||||||||
| LCD display | UPS status, input/output voltage and frequency,battery voltage, capacity,load temperature,history records,adjust Voltage,ECO mode | ||||||||
| Communication | RS232, AS400,RS485,SNMP (Optional),USB(Optional) | ||||||||
| Efficiency | >95% | ||||||||
| Protection | IP21 | ||||||||
| Working temperature | 0~40°C | ||||||||
| Humidity | 0~95% non-condensing | ||||||||
| Storage temperature | -25°C~70°C | ||||||||
| Elevation | 1000M | ||||||||
| Noise | <45dB | ||||||||
| Dimension(mm) | 210x600x560 | 300x586x850 | 350x675x920 | 430x792x1060 | |||||
| Weight(kgs) | 142 | 148 | 200 | 225 | 268 | 325 | 389 | 389 | |
