Delivers Reliable Performance Over Time
· World-class manufacturer of crystalline silicon photovoltaic modules
· Fully automatic facility and world-class technology
· Rigorous quality control to meet the highest standard: ISO 9001 ,ISO 14001 and ISO 45001
· Tested for harsh environments salt mist, ammonia corrosion and sand blowing test: IEC 61701 ,IEC 62716.DIN EN 60068-2-68
· Long term reliability tests
· 2x100% EL inspection ensuring defect-free modules
· After 25 years our solar panel keeps at least 80% of itsinitial power output
· Frame design makes module compatible with all rackingand installation methods
ELECTRICAL CHARACTERISTICS I STC*
Nominal Power Watt Pmax(W)* | 335 | 340 | 345 | 350 | 355 | 360 |
Power Output Tolerance Pmax(%) | 0~+3 | 0-+3 | 0~+3 | 0~+3 | 0~+3 | 0~+3 |
Maximum Power Voltage Vmp(V) | 38.00 | 38.20 | 38.40 | 38.60 | 38.80 | 39.00 |
Maximum Power Current Imp(A) | 8.82 | 8.91 | 8.99 | 9.07 | 9.15 | 9.24 |
Open Circuit Voltage Voc(V) | 46.70 | 46.90 | 47.10 | 47.30 | 47.50 | 47.70 |
Short Circuit Current Isc(A) | 9.16 | 9.22 | 9.28 | 9.37 | 9.46 | 9.54 |
ELECTRICAL CHARACTERISTICS | NMOT*
Maximum Power Pmax(Wp) | 248.30 | 252.40 | 256.20 | 260.30 | 263.20 | 267.30 |
Maximum Power Voltage Vmpp(V) | 35.60 | 35.90 | 36.10 | 36.30 | 36.40 | 36.60 |
Maximum Power Current Impp(A) | 6.98 | 7.04 | 7.10 | 7.17 | 7.23 | 7.30 |
Open Circuit Voltage Voc(V) | 43.10 | 43.30 | 43.50 | 43.70 | 43.80 | 44.00 |
Short Circuit Current Isc(A) | 7.42 | 7.46 | 7.51 | 7.59 | 7.66 | 7.72 |
