| Parameters/Model | PowerEco-250kW/464kWh | PowerEco-250kW/522kWh | |
DC side parameter | Max Voltage | 950V | |
| Max Current | 340A | 406A | |
| Voltage Range | 650~950V | ||
| AC grid connection parameter | Max.Apparent Output | 275kW | |
| Max.Input Active Power | 250kW | ||
| Nominal Voltage | 400Vac,3P3W+PE/3P4W+PE | ||
| Max.Input Current | 400A | ||
| Nominal Input Frequency | 50/60Hz | ||
| AC off-grid parameter | Nominal Voltage | 400V,3P3W+PE/3P4W+PE | |
| Max Output Current | 416A | ||
| Nominal Frequency | 50/60Hz | ||
| Battery parameters | Cell Capacity | 280Ah(LFP) | 314Ah(LFP) |
| Capacity | 464kWh | 522kWh | |
| Nominal Voltage | 832V | ||
| Voltage Range | 728~910V | ||
| C Rate | ≤0.5C | ||
| System level parameters | HMI | 7 Inch touch screen | |
| Fire Safety | Perfluorohexane fire protection/Aerosol | ||
| Cooling Method | Liquid Cooling | ||
| Operating Temp. | -20~55℃ | ||
| IP Degree | IP54 | ||
| Dimension(W*D*H) | 2400*1400*2300mm | ||
| Weight | <4500Kg<4600Kg | ||
| Others | MPPT | 50KW*4(Optional) | |
| STS | / | ||
| Certification | Undergoing Certification | ||
*The specifications shall prevail
