| Parameters/Model | CS5000H-5-P | CS5000H-10-P | CS5000H-15-P | CS5000H-20-P | |
| Inverter output | Rated output power | 5500W | |||
| Peak power | 11000VA | ||||
| Rated output voltage | 230Vac Single-phase | ||||
| Frequency | 50/60±0.3Hz | ||||
Switching time | 10ms | ||||
| PVinput parameters | Number of MPPTs | 2 | |||
| PV open-circuit voltage | 500/500V | ||||
| Maximum input power | 4000+4000V | ||||
| MPPT voltage range | 120~450Vdc | ||||
| Maximum PV input current | 16/16A | ||||
Maximum short-circuit current | 27/27A | ||||
| Mains/ generator input | Input voltage range | 90~280Vac | |||
| Input frequency range | 50/60Hz | ||||
| Maximum bypass current | 40A | ||||
| Battery Parameters | Battery type | LFP | |||
Battery rated voltage | 51.2 | ||||
| Voltage range | 46.4~58.4V | ||||
| Battery capacity | 5.12kWh | 10.24kWh | 15.36kWh | 20.48kWh | |
| Maximum charge/discharge rate | 0.5/1C | ||||
| Operating conditions | Charging temperature range | 5~55℃ | |||
Discharging temperature range | -15~60℃ | ||||
Humidity | 5~95% | ||||
Cooling method | Air cooling | ||||
| Weight | 107Kg | 157Kg | 207Kg | 257Kg | |
| Size(W*D*H) | 725*515*445mm | 725*515*585mm | 725*515*725mm | 725*515*865mm | |
| Communication method | WIFI/RS485 | ||||
| Others | Certification | IEC62619、IEC62109、CE-EMC | |||
*The specifications shall prevail
