Case dimensions | 482.6mm×177.0mm×283.0mm(W×H×D) |
Normal working temperature | -40℃～70℃ |
Extreme working temperature | -40℃～85℃ |
Storage and transportation | -40℃～85℃ |
Relative humidity | 5%～95% |
Atmospheric pressure | 80kPa～106kPa |
DC working power | 220V / 110V, allowable deviation: -20％～+15％ |
Remote signal input | DC110V / DC220V, passive contact input, isolated by optocoupler |
Power consumption of DC power circuit | Under normal operation, the power consumption of entire device is no more than 30W |
Under tripping action, the power consumption of entire device is no more than 40W. | |
Tripping action time | The tripping action time is no more than 5ms |
Input response time | The input response time (not including the anti-shake time) should be no more than 5ms. |
