| Product Specifications | |
| Insulation material | PPE |
| Rated current | 35(TUV) |
| Rated voltage | 1500VDC |
| Test voltage | 8KV(50Hz,Imin) |
| Typical contact resistance | ≤0.35mΩ |
| Contact material of MC4 connector | Copper, Tin, Plated |
| Degree of protection | IP68（1m,1H) |
| Safety degree | II |
| Flames class | UL94-V0 |
| Upper limiting temperature | 110°c |
| Suitable cable cross sections | 2.5~10mm2 /14~8AWG |
| Ambient temperature range | -40°c until+85°c |
