Cell material: lithium iron phosphate
Series and parallel method (S series, P parallel): 16S1P
Nominal voltage: 51.2V
Nominal capacity: 135Ah
Size (mm): 1020*540*75mm
Weight: 85kg
Parallel support: support parallel Anderson interface
Output port mode: Anderson interface
Charging method: CC/CP/VP
Charging current: 0.2C (standard)
Maximum charging current: Maximum 1C @ 25℃
Charging cut-off voltage: 58.4V/CELL
Discharge method: CC/CP/VP
Discharge current: 0.5C
Maximum discharge current: Maximum 1.2C @ 25℃
Discharge cut-off voltage: 43.2V
Display: LCD
Communication interface: 485/232/CAN
Charging working temperature: charging: 0~ + 50°C
Discharge working temperature: Discharge: -20- + 55°C
Warranty period: 36~60 months
Scope of application: hospitals, bank data centers, wall-mounted homes, small and medium-sized enterprises, energy storage, backup power, wind and solar hybrid systems, offices, base stations, and other uninterrupted energy storage power supplies.
