Model | GH3600TL | GH4600TL | GH5000TL |
DC data | |||
Maximum PV Input power | 5.2KW | 6.5KW | 7KW |
Maximum DC voltage | 500V | ||
Starting voltage | 150V | ||
Rated voltage | 360V | ||
MPPT operating voltage range | 120V~430V | ||
Number of mppts | 2 | ||
Maximum short-circuit current per MPPT | 18.9A | ||
Maximum Input current per MPPT | 15A | ||
Battery data | |||
Battery type | Lithium-Ion / Lead-acid batteries | ||
Operating voltage range | 41.6V~58.5V | ||
Maximum charge/discharge current | 80A/85A | 95A/100A | |
Exchange data | |||
Rating | 3.6KW | 4.6KW | 5KW |
Max. apparent power | 3960VA | 4600VA | 5500VA |
Rated voltage (range) | 230V | ||
Rated frequency (range) | 50Hz/60Hz | ||
Max. output current | 17.2A | 22A | 23.9A |
Power factor | 0.8 Ahead~0.8 Behind | ||
Common data | |||
Dimensions | 350*580*230 mm | ||
Total weight | 25kg | ||
IP protection level | IP65 | ||
Range of working temperature | -40℃~60℃ | ||
Relative humidity | 0-95% No condensation | ||
Maximum working altitude | > 2000m | ||
Cooling method | Natural cooling | ||
