Model | OH3600TL | OH5000TL | OH5500TL |
Lnverter output | |||
Rated output power | 3.6KW | 5KW | 5.5KW |
Max. peak power | 7.2KW | 10KW | 11KW |
Rated output voltage | 230Vac (Single phase) | ||
Rated output frequency | 50/60Hz | ||
Battery data | |||
Battery type | Lithium-Ion battery / Lead-acid battery / User-defined | ||
Rated battery voltage | 24Vdc | 48Vdc | |
Max. PV MPPT charge current | 100A | 80A | 100A |
Exchange data | |||
Maximum photovoltaic Input power | 5KW | 6KW | |
Maximum Input current | 18A | 27A | |
Max. PV open circuit voltage | 500Vdc | ||
MPPT voltage range | 40~450Vdc | 120~430Vdc | |
Input voltage range | 170~264V | ||
Frequency range | 50/60Hz | ||
Bypass over-load current | 20A | 40A | |
Common data | |||
Dimensions | 284*417*92 mm | 300*485*120 mm | |
Weight | 8.5kg | 9.5kg | |
IP protection level | IP20 | ||
Range of working temperature | -10~50℃,Derating>40℃ | ||
Noise | <60db> | ||
Cooling method | Lntelligent air cooling | ||
