IndicatorsTechnical ParametersInput voltage380V，-30%~﹢20%Input frequency50Hz，±10%Connection mode3P4WRated capacityComplete machine:100~400kvarResponse time≤5msPower lossActive module <3%, Passive module <1%Compensation functionHarmonics, reactive power, three-phase imbalance; priority selectable and settableControl accuracyNot less than 2.5%CT scan requirements5A, using grid side current for sampling.TSC moduleReactor 7% or 14%, voltage levels at 480V or 525V, control signal for 12 channels (12V or nodes), both group compensation and individual compensation can be customized.ProtectionMultiple protection functions such as overcurrent, overheating, over and under voltage protection.IP gradeIP30; higher IP grades for the complete machine can be customized.Ambient temperatureWorking temperature: -10°C ~ 50°C (derating above 40°C);Storage temperature: -25°C ~70℃Ambient humidity≤95% (45°C), no condensationAltitude<2000m; for altitudes over 2000 meters, use according to derating requirements specified in GB/T3859.2Overall dimensions(W×D×H: mm)800×1000×2200; dimensions of the complete machine can be customizedInstallation methodComplete machine: freestanding installationDisplay screen7-inch touch screenDisplay contentVoltage, load current, compensating current, grid-side current, voltage distortion rate, current distortion rateCommunication interface and communication modeRS485, LAN, WiFi (optional configuration)Communication protocolModbus Protocol
