Model： | NKH-5KW | NKH-10KW | ||||
Rated Power | 5000W | 10000W | ||||
Rated Input Voltage （Settable) | 208∨AC/220VAC/230VAC/240VAC | |||||
Mains Input | Mains Supply Input Voltage Range | 170-280VAC；90-280VAC | ||||
Mains Supply Input Frequency | 50Hz/60Hz（Auto detection） | |||||
Output | Rated Output Voltage （settable） | 208VAC/220VAC/230VAC/240VAC士5% | ||||
Surge Power | 20000VA | |||||
Efficiency | 94% | |||||
Switching Time | 10ms | |||||
Overload power | 1min@102‰110%Load，10ε@110‰-130%Load，3s@130‰150%Load，0.2s@>150%Load | |||||
Battery And AC Charging | Battery Voltage Rating | 51.2VDC | ||||
Floating Charge Voltage | 54VDC | |||||
Overcharge Protection | 64VDC | |||||
Maximum Charging Current | 80A 160A | 160A | ||||
PV Charging | Maximum PV Array Power | PV 5500w | 1 way PV 5500w；2wayPV 5500w | |||
1 way PV 5500w；2wayPV 5500w | ||||||
MPPT Range Operating Voltage | 120-430VDC | |||||
Maximum PV Array Open Circuit Voltage | 450VDC | |||||
Maximum Charge Current | 80A | 160A | ||||
Maximum Efficiency | 98% | |||||
Mains Supply And PV Charging | Mains Supply And, Mains Supply and PV charging Maximum | 80A | 160A | |||
PV Charging charging current (AC charger plus PV charger) | ||||||
Basic Specifications | Communication Interface | vUSB/RS232/GPRS/WIFI | ||||
Working Environment | Humidity | 5% to 95% relative humidity(non-condensing) | ||||
Operating Temperature Range | 0℃-55℃ | |||||
Storage Temperature | -15℃-60℃ | |||||
Dimension（L*W*H） | 770*410*222.5mm | 930*410*222.5mm | ||||
