Modle | HES 3.0 | HES 10.0 |
| Battery Type | Sodium ion (Na+) | Sodium ion (Na+) |
| Rated energy | 3.36kWh | 9.6kWh |
Nominal capacity | 70Ah | 200Ah |
Discharge voltage | 32~64V | 32~64V |
Charge voltage | 65V | 65V |
Operating temperature | -40℃ ~ 60℃ | |
Continuous charge current | 35A | 100A |
| Peak charge current | 70A | 125A |
Continuous discharge current | 50A | 100A |
Peak discharge current | 100A | 125A |
Rated discharge power | 2kW | 5kW |
Maximum discharge power | 5kW | 10kW |
IP protection level | IP31 | |
Extensibility | Support parallel connection (refer to the user manual） | |
| DOD | 90% | |
| Lnstallation method | Wall mounted or floor | |
Dimensions | 830*460*200mm | 980*460*200mm |
Weight | 65kg | 115kg |
Authentication | UN, CE | |
Communication protocol | CAN2.0 / RS485 | |
Rated voltage | 48V | |
Warranty | 5 Year | |
Cycle life | >5000 | |
