Power output up to 625W
Additional power generation gain up to 30%
Dual-glass design, with a broader application range
Suitable for use in deserts, farms and near coastal areas
Front side can withstand a load of 5400 Pa, and the back side can withstand a load of 2400 Pa
Lower first-year degradation rate (1%) and annual degradation rate (0.4%)
Half-cell technology reduces localized power loss
Lower temperature coefficient and operating temperature, leading to more power generation
Class C fire resistance test passed
IP68 ensures long-term reliability
New generation TOPCon technology, with no wraparound coating, no leakage, and low hot spot risk
| Mechanical Parameters | |
|---|---|
| Cell | 132 Half-Cut Cells |
| Cell Type | Monocrystalline/N-Type,16BB |
| Dimension | 2382x1134x30 mm |
| Weight | 33.2kg |
| Connector Type | MC4 EVO2/MC4 compatible |
| Junction Box | IP68 rated, with 3 Diodes |
| Cable Length | 4mm2, Wire length of 300mm （customizable） |
| Front Glass | 2.0mm Semi-tempered glass |
| Back Glass | 2.0mm Semi-tempered glass |
| Temperature Characteristics | |
|---|---|
| Nominal Operating Cell Temperature (NOCT) | 42±2°C |
| Peak Power [Pmax]Temperature Coefficient | -0.295%/℃ |
| Open Circuit Voltage (Voc) Temperature Coefficient | -0.257%/℃ |
| Short Circuit Current (lsc) Temperature Coefficient | +0.044%/°C |
| Limit Parameters | |
|---|---|
| Operating Temperature | -40°C~+85°C |
| Maximum System Voltage | 1500V DC （IEC） |
| Maximum Fuse Rating Current | 30A |
| Power Tolerance | 0~+5W |
| Packaging Configuration | |
|---|---|
| Module per box | 36 pieces |
| Module per 40'container | 720 pieces |
