Product Advantage
The Xpower ESS boasts an impressive peak efficiency of 98% and supports up to 200% oversizing for maximized energy yield. Its capability to handle up to 16A per PV input string and support for 100A generators ensures robust power handling.
- Integrated ARC fault protection and rapid shutdown transmitter
- NEMA 4X protection level
- Automatic black start function
- Max. 100A generator supported, depending on different BI Version
- Smart load management
- Micro-grid ready, supporting real-time power balance
- Support multiple power distribution solutions (Partial or Whole Home)
- VPP ready, SolaX cloud support resource aggregator (IEEE 2030.5, OpenADR)
- Stacked installation, saving installation costs
- Up to 3 MPPTs
- Up to 200% oversizing allowed
- Maximum 16A PV input current, support high power solar panel
- Peak efficiency: 98%
- Up to 4 ESS in parallel
- Support Maximum 200A main panel
- Compatible with 120/208V grid systems
Product Parameters
| Rated Output Power [kW] | 3.8 / 5.0 / 6.0 / 7.6 |
| Nominal Capacity [kWh] | 10 / 15 / 20 |
| Usable Energy | 9 / 13.5 / 18 |
| Degree of Protection | NEMA 4X |
| Altitude | 9843 / 3000 MAX |
| Cooling | Natural convection |
| Topology | Transformerless |
| Communication Interfaces | RS485, CAN, WIFI (optional) / 4G (optional), Dry Contact |
| Warranty | 12 years |
