Bi-directional measurement of import active energy and reactive energy
Neutral measurement(Optional)
Instantaneous parameters of voltage, current, power, power factor, frequence,etc.
Max demand measured by total and each tariff with timestamp, integration period is configurable from 1 to 60 minutes.
Support up to 8 TOU configurable tariffs
Support 8 weeks profile, 8 seasons profile
Support recording load profile up to 90days and configurable 30 channels with date and time.
Record of active and reactive energy with different tariffs with configurable time interval.
Local: Optical Port, RS485
CIU: PLC/RF/M-BUS
Remote: RF/RF-Mesh/Wi-SUN/G3-PLC/HPLC
Internal load switch designed for load management and credit management.
Configurable disconnection of load switch upon tampering events, credit balance run out, Overload, Power off etc.
Capable to record events includes Standard events, fraud detection events,
Communication events, Power quality event, etc.
Support up to 600 events.
Magnetic Field
Reverse Energy
Meter Cover Open/Terminal Cover Open
Support Credit level Indication and Low Credit alarming
Support friendly mode and over draft mode
Keypad (optional) to input Token/Remotely charge
