Industry and commerce |
● Seamless Integration and High Efficiency
Designed for quick deployment and energy savings with an 89% efficiency rate.
● Advanced Safety Features
Equipped with IP54 protection, multiple safety certifications, and a 15-year corrosion-resistant enclosure.
● Scalable and Versatile
Modular architecture for easy parallel expansion and suitability for a wide range of applications.
● Intelligent Monitoring and Temperature Control
Real-time app monitoring and advanced thermal management for reliable performance in all conditions.
| Model | Star 258 / Pro | Star 289 / Pro | Star 385 / Pro |
| System Parameters | |||
| Battery Type | LFP | ||
| Rated Capacity | 258kWh | 289kWh | 385kWh |
| Rated Power | 125kW | 135kW | / |
| Cooling Type | Liquid Cooled | ||
| IP Protection Level | IP54 | ||
| Corrosion-proof Grade | C4H | ||
| Fire Protection System | Aerosol Fire Fighting | ||
| Noice | ＜75dB (1m Away from the System) | ||
| Dimension | (1588±10)*(1380±10)*(2450±10)mm | 1578mm*1380*2500mm | |
| Weight | 2950±150kg | 3050±150kg | ≤3900kg |
| Working Temp. Range | -30℃~55℃ (Derating When＞45℃) | ||
| Relative Humidity Range | 0~ 95 % (Non-condensing) | ||
| Communication Interface | RS485 / CAN | ||
| Communication Protocol | Modbus RTU | ||
| Cycle Life | ≥8000 | ≥10000 | ≥10000 |
| System Certification | GB/T 36276, GB/T 34131, GB/T 34120, IEC62619, UL1973, UL9540A, UN 38.3, IEC/EN 61000 | ||
| Max. Efficiency of System | ＞89% | ＞89% | ＞93% |
| Quality Guarantee | ≥5 Years | ||
| EMS | Possess | Possess | Not Possess |
| Application Scenarios | New Energy Generating, Distributed Generating,Micro-grid ESS, EV Charge, City ESS, Industrial & Commercial ESS, etc. | ||
| DC Battery Parameters | |||
| Rated Voltage | 921.6V | 921.6V | 1228.8V |
| Voltage Range | 720 ~ 1000V | 720 ~ 1000V | 960 ~ 1401.6V |
| Charge & Discharge Ratio | 0.5P | 0.5P | 0.5P |
| Max. Input DC Power | 125kW | 135kW | / |
| AC Side Parameters | |||
| Rated AC Voltage | 400V | 400V | / |
| Rated Output Frequency | 50/60Hz | 50/60Hz | / |
| Rated Power | 125kW | 135kW | / |
| Rated Current | 182A | 196A | / |
| Max. AC Power | 150kW (60S 25℃) | 162kW (60S 25℃) | / |
| AC/DC Converter Grid-connected Certification | GB/T 34120-2017, GB/T 34133CE, EN50549-1:2019+AC.2019-04, CEI 0-21, CEI 0-16, NRS097-21-1:2017, EN50549, C10/11:2019, EN50549-1&10, G99, VDE-AR-N 4105, VDE-AR-N 4110, VDE-AR-N 4120, UNE 217002, UNE 217001, NTS631, TOR Erzeuger, NRS 097-2-1, AS 4777.2 | ||
