Summary
Introducing the FOXESS T10 1.0 20kW Three Phase String Inverter – a high-performance, on-grid solar solution engineered for residential and commercial applications. Featuring dual MPPT technology, this solar inverter ensures maximum energy harvest with 98.6% efficiency, delivering reliable and efficient power conversion for solar energy systems. Designed with advanced safety features including DC reverse polarity, anti-islanding, and over-temperature protection, the T10 1.0 offers durability and performance in diverse environments. Compact and lightweight at 29kg with dimensions of 475x384x186mm, it is ideal for seamless integration into modern solar installations. Built to international standards, this inverter supports grid-tied systems with a rated voltage of 400V AC and comes with a 9-year warranty, making it a trusted choice for sustainable energy solutions.More
Specifications
Application:
On-Grid Solar System
Output Power:
3-25KW
  • String Inverter 20kW Three Phase Dual MPPT On-Grid Solar System FOXESS
  • String Inverter 20kW Three Phase Dual MPPT On-Grid Solar System FOXESS
  • String Inverter 20kW Three Phase Dual MPPT On-Grid Solar System FOXESS
  • String Inverter 20kW Three Phase Dual MPPT On-Grid Solar System FOXESS

Key attributes

Output Type
Three Phase
Inverter Efficiency
98.60%
Place of Origin
Zhejiang, China
Model Number
T10 1.0
Brand Name
FOXESS
Size
475*384*186MM
Type
DC/AC Inverters
Weight
29KG
Rated grid voltage(AC voltage range)
3/N/PE,400V
Rated grid Frequency
50/60Hz , ±5Hz
DC Reverse Polarity Protection
YES
Anti-islanding Protection
YES
Leakage Current Protection
YES
Insulation Resistance Detection
YES
Over-Current Protection
YES
Over-Temperature Protection
YES
DC/AC Surge Protection
YES
Warranty
9 Years

Packaging and delivery

Selling Units
Single item
Single package size
62X52X33 cm
Single gross weight
35.000 KG
