| Model | SU-AIO3608 |
| ACInput | |
| RatedInputVoltage(VAC) | 208/220/230/240L+N+PE |
| VoltageRange(VAC) | 90-280V(normalmode),170-280±3(UPSmode) |
| Frequency(Hz) | 50/60(Auto-adaptive) |
| ACOutput | |
| RatedCapacity(kW) | 3.6 |
| SurgePower(kVA) | 5.7 |
| Voltage(VAC) | 208/220/230/240 |
| PowerFactor(PF) | 1 |
| Frequency | 50/60Hz±0.1% |
| SwitchTime(ms) | 10 |
| Waveform | PureSineWave |
| OverloadCapacity(BatteryMode) | 60s@102%-110%;10s@100%-130%;3s@130%-150%;0.2s@≥150% |
| ChargerEfficiency(BatteryMode) | 92.7%@24VDC |
| Charger(PV/AC) | |
| SolarChargerType | MPPT |
| Max.InputCurrent/Power | 18A/5000W |
| OperatingVoltageRange(VDC) | 40-450 |
| Max.PVOpenCircuitVoltage(VDC) | 500 |
| Max.PVChargeCurrent(A) | 100 |
| Max.ACChargeCurrent(A) | 100 |
| Max.TotalChargeCurrent(PV+AC)(A) | 100 |
| Battery | |
| NominalBatteryVoltage | 25.6VDC |
| RatedEnergy | 8kWh@25℃ |
| UsableEnergy(90%DepthofDischarge) | 6.3kWh |
| Max.Charge/DischargeCurrent | 100A/100A |
| OperatingVoltageRange | 20.0Vdc-29.2Vdc |
| OperatingTemperature | -10℃-+50℃ |
| Interface | |
| Display | LCD |
| Communication | RS485/RS232/USB/DryContact |
| Monitoring | WiFi(Optional) |
| GeneralData | |
| IngressProtection | IP21 |
| OperatingTemperature | -10℃-50℃ |
| StorageTemperature | 5%-95%Non-condensing |
| Max.OperatingAltitude | -15℃-60℃ |
| General | |
| RatedDimensions(Productsize,mm) | 440*245*760mm |
| Weight |
