| Model | SUN-120K-G01P3 | SUN-125K-G01P3 | SUN-130K-G01P3 | SUN-135K-G01P3 | SUN-136K-G01P3 |
| PV String Input Date | |
| Max. PV Input Power(kW) | 180 | 187.5 | 195 | 202.5 | 204 |
| Max. PV Input Voltage(V) | 1100 |
| Start-up Voltage(V) | 250 |
| MPPT voltage range(V) | 200-1000 |
| Rated PV Input voltage(V) | 600 |
| Max. Input Short Circuit Current (A) | 60+60+60+60+60+60+60+60 |
| Max. Operating PV Input Current(A) | 40+40+40+40+40+40+40+40 |
| No. of MPP Trackers/No. of Strings per MPP Tracker | 8/4+4+4+4+4+4+4+4 |
| AC Output Side | |
| Rated AC Output Active Power(kW) | 120 | 125 | 130 | 135 | 136 |
| Max. AC Output Apparent Power(kVA) | 132 | 135 | 135 | 135 | 136 |
| Rated AC output current (A) | 181.9/174 | 189.4/181.2 | 197/188.5 | 204.6/195.7 | 206.1/197.2 |
| Max. AC Output Current(A) | 200/191.4 | 204.6/195.7 | 204.6/195.7 | 204.6/195.7 | 206.1/197.2 |
| Rated output voltage/range (V) | 220/380V, 230/400V 0.85Un-1.1Un |
| Grid Connection Form | 3L+N+PE |
| Rated Output Grid Frequency/range(Hz) | 50/45-55, 60/55-65 |
| Power Factor Adjustment Range | 0.8 leading to 0.8lagging |
| Total Current Harmonic Distortion THDi | <3% |
| DC Injection Current | <0.5%ln |
| Efficiency | |
| Max. Efficiency | 98.8% |
| Euro Efficiency | 98.2% |
| MPPT Efficiency | ＞99% |
| Equipment Protection | |
| DC Reverse Polarity Protection | Yes |
| AC Output Overcurrent Protection | Yes |
| AC Output Overvoltage Protection | Yes |
| AC Output Short Circuit Protection | Yes |
| Thermal Protection | Yes |
| Insulation Impedance Detection | Yes |
| DC Component Monitoring | Yes |
| Arc Fault Circuit Interrupter (AFCI) | Optional |
| Anti-islanding Protection | Yes |
| Residual Current Detection | Yes |
| Surge Protection Level | TYPE II(DC),TYPE II(AC) |
| DC Switch | Yes |
| Interface | |
| Communication Interface | RS485/RS232 |
| Monitor Mode | GPRS/WIFI/Bluetooth/4G/LAN(optional) |
| General Data | |
| Operating Temperature Range (°C) | -25 to +60℃, >45℃ Derating |
| Permissible Ambient Humidity | 0~100% |
| Permissible Altitude (m) | 4000m |
| Noise (dB) | ≤ 65 |
| Ingress Protection(IP) Rating | IP 65 |
| Inverter Topology | Non-Isolated |
| Over Voltage Category | OVC II(DC),OVC III(AC) |
| Cabinet Size (WxHxD mm) | 1006mm*516mm*325.5mm（Excluding connectors and brackets） |
| Weight [kg] | 103 |
| Warranty | 5 years |
| Type Of Cooling | Intelligent air cooling |
| Grid Regulation | IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4105 |
| Safety EMC/Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
