Technical parameters:
Weight :4.7kg(2.6kg)
★ Size :160mm×67mm×299.5mm(height × width × depth, without panel connector)
Cooling method: forced air cooling
★ Operating temperature :-10℃ ~ 40℃
Ac input voltage VAC:380(-15% ~ 20%)(220)
Dc output voltage VDC:176 ~ 300(88 ~ 150)(176 ~ 260)
Dc output current A:10(5) (10)(5)
★ Power factor: ≥ 0.94
★ Efficiency: ≥ 95%(1.5kW model 93%)
Stability accuracy: ≤ ±0.5%
Stable flow accuracy: ≤ ±1%
★ Peak ripple coefficient: ≤ 0.5%
Noise: ≤ 55dB
Parallel machine uneven mobility: ≤ ±3%
★ Communication mode :RS485, CAN
Main features of the module:
High efficiency, high working frequency, small size, light weight, high reliability, digital control, digital flow, module built-in isolation diode, module for LED digital tube display, respectively set up, down, confirm button, simple operation, can not use tools to disassemble fan, electromagnetic compatibility in line with national standards.
