● Dual-Sided Adhesion: Provides strong, reliable bonding on both sides, capable of replacing screws and mechanical fasteners.
● Thermal Conductivity: Transfers heat efficiently with a thermal conductivity of 1.2W/m.k.
● Temperature Resistance: Operates effectively in temperatures ranging from -20°C to 120°C, suitable for a variety of environments.
● Tear Resistance: The fiberglass base offers enhanced durability and resistance to tearing.
● Strong Adhesion: Delivers excellent bonding strength to various surfaces.
● Electrical Insulation: Provides reliable electrical insulation to protect sensitive components.● Surface Preparation: Clean and dry the surfaces to ensure they are free from dust, grease, and contaminants.
● Cutting and Peeling: Cut the tape to the required size, then peel off the protective liners from both sides.
● Positioning: Align and place the tape between the heat-generating component and the heat sink or other surfaces.
● Application of Pressure: Apply firm pressure to ensure a secure bond and full contact between surfaces.
| Testing Item | Unit | Testing Value | Testing Method |
| Substrate | - | Glass Fabric | - |
| Colour | - | White | Visual |
| Thickness | MM | 0.7 | - |
| Peel Strengthunder180° | (PSTC-101)(N/25MM) | ＞20 | PSTC-1 |
| Retention | （1KG/INCH/25℃） | ＞48 | PSTC-1 |
| Adhesion | KG/IN | 1.5 | PSTC-1 |
| Initial Viscosity | KG/IN | 1.5 | PSTC-1 |
| Breakdown Voltage | KV/MM | 7 | ASTM D149 |
| Long-termHighest Temperature resistance | ℃ | 80 | EN 344 |
| Short-termHighest Temperature | ℃ | 120 | EN 344 |
| Working Temperature | ℃ | -20～120 | EN 344 |
| Conductivity | W/M.K | ≥1.2 | ASTM D5470 |
