| Model | SUN-70K-G03 | SUN-75K-G03 | SUN-80K-G03 | SUN-90K-G03 | SUN-100K-G03 | SUN-110K-G03 |
| PV String Input Date | |
| Max. PV Input Power(kW) | 91 | 97.5 | 104 | 135 | 150 | 150 |
| Max. PV Input Voltage(V) | 1000 |
| Start-up Voltage(V) | 250 |
| MPPT voltage range(V) | 200-850 |
| Rated PV Input voltage(V) | 600 |
| Max. Input Short Circuit Current (A) | 60+60+60+60 | 60+60+60+60+60+60 |
| Max. Operating PV Input Current(A) | 40+40+40+40 | 40+40+40+40+40+40 |
| No. of MPP Trackers/No. of Strings per MPP Tracker | 4/4+4+4+4 | 6/4+4+4+4+4+4 |
| Rated AC Output Active Power(kW) | 70 | 75 | 80 | 90 | 100 | 110 |
| Max. AC Output Apparent Power(kVA) | 77 | 82.5 | 88 | 99 | 110 | 121 |
| Rated AC output current (A) | 106.1/101.5 | 113.6/108.7 | 121.2/115.9 | 136.4/130.4 | 151.5/144.9 | 166.7/159.4 |
| Max. AC Output Current(A) | 116.7/111.6 | 125/119.6 | 133.3/127.5 | 150/143.5 | 166.7/159.4 | 183.3/175.4 |
| Rated output voltage/range (V) | 220/380V, 230/400V 0.85Un-1.1Un |
| Grid Connection Form | 3L+N+PE |
| Rated Output Grid Frequency/range(Hz) | 50/45-55, 60/55-65 |
| Power Factor Adjustment Range | 0.8 leading to 0.8lagging |
| Total Current Harmonic Distortion THDi | <3% |
| DC Injection Current | <0.5%ln |
| Max. Efficiency | 98.7% | 98.8% |
| Euro Efficiency | 98.1% | 98.2% |
| MPPT Efficiency | ＞99% |
| DC Reverse Polarity Protection | Yes |
| AC Output Overcurrent Protection | Yes |
| AC Output Overvoltage Protection | Yes |
| AC Output Short Circuit Protection | Yes |
| Thermal Protection | Yes |
| Insulation Impedance Detection | Yes |
| DC Component Monitoring | Yes |
| Arc Fault Circuit Interrupter (AFCI) | Optional |
| Anti-islanding Protection | Yes |
| Residual Current Detection | Yes |
| Surge Protection Level | TYPE II(DC),TYPE II(AC) |
| DC Switch | Yes |
| Communication Interface | RS485/RS232 |
| Monitor Mode | GPRS/WIFI/Bluetooth/4G/LAN(optional) |
| Operating Temperature Range (°C) | -25 to +60℃, >45℃ Derating |
| Permissible Ambient Humidity | 0~100% |
| Permissible Altitude (m) | 4000m |
| Noise (dB) | ≤ 55 |
| Ingress Protection(IP) Rating | IP 65 |
| Inverter Topology | Non-Isolated |
| Over Voltage Category | OVC II(DC),OVC III(AC) |
| Cabinet Size (WxHxD mm) | 824mm*516mm*312.7mm（Excluding connectors and brackets） |
| Weight [kg] | 81 |
| Warranty [year] | 5 years |
| Type Of Cooling | Intelligent air cooling |
| Grid Regulation | IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4105 |
| Safety EMC/Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
