● Exceptional Thermal Conductivity: Provides an impressive thermal conductivity of 4.0 W/m.K, facilitating efficient heat transfer.
● Minimal Thermal Resistance: Significantly reduces thermal impedance, optimizing the thermal management of electronic devices.
● Curing Characteristics: Transforms from a gel to a solid state upon curing, creating a durable and stable thermal interface.
● Consistent Performance: Maintains excellent thermal and mechanical stability over a wide range of temperatures and operating conditions.
● Non-Corrosive and Non-Conductive: Safe for use with sensitive electronic components, providing both thermal and electrical insulation.
● High Dielectric Strength: Ensures superior electrical insulation properties.
● Flexible Application: Compatible with both automated dispensing equipment and manual application methods, offering versatility in usage.
● Consumer Electronics: Ideal for high-performance consumer devices such as gaming consoles, high-end laptops, and advanced smartphones.
● Automotive Electronics: Perfect for thermal management in advanced automotive systems, including ECUs, LED lighting systems, and electric vehicle battery packs.
● Telecommunications: Suitable for high-power telecom equipment such as base stations, data centers, and network servers.
● Industrial Electronics: Provides efficient thermal management for industrial control systems, power converters, and other critical industrial electronics.
● Medical Equipment: Ensures reliable thermal performance in medical imaging devices, patient monitoring systems, and other healthcare electronics.
| Feature | Value | Unit | Test Method |
| Part A Color | Red | -- | Visual |
| Part B color | White | -- | Visual |
| Density | 3.15 (±0.5) | g/cc | ASTM D792 |
| Mixing Ratio | 1:1 | -- | By weight or volume |
| Cure Condition | 24 | H | 25℃ |
| 15 | Min | 100℃ | |
| Thermal Conductivity | 4.0(±0.2) | W/m·K | ASTM D5470 |
| Color | Pink | -- | Visual |
| Thermal Impedance | ≤0.75 | ℃-in2/W | ASTM D5470 |
| @20psi&1mm | |||
| Hardness | 35 | Shore C | ASTM D2240 |
| Tensile Strength | ≥0.1 | MPa | ASTM D412 |
| Extension Rate | ≥50 | % | ASTM D412 |
| Flammability Rating | V-0 | -- | UL 94 |
| Working Temperature | -50~160 | ℃ | IEC 60068-2-14 |
| Breakdown Voltage | ≥10 | Kv/mm | ASTM D149 |
| Volume Resistivity | ≥1012 | Ω·cm | ASTM D257 |
| Dielectric Constant | ≥2 | @1MHz | ASTM D150 |
| Dielectric loss | ≤0.1 | @1MHz | ASTM D150 |
