| Part Number | S585V55-K7 |
|---|---|
| Nominal Capacitance(F) | 1667 |
| Operating Voltage Window(V) | 420～590 |
| Surge Voltage(V) | 600 |
| Stored Energy(kWh) | 45 |
| Standard Charge Current(A) | 570 |
| Standard Discharge Current(A) | ≤570 |
| Maximum Charge/Discharge Current(<20s)(A) | 1140 |
| Time for Charging(min) | 20 |
| Operating Temperature(oC) | -25～+55 |
| Storage Temperature(oC) | -30～+65 |
| Protection Level | IP67 |
| Electric Property | Overvoltage, overcurrent, overheat, overload, short circuit, DC leakage protection, etc |
| Capacitor Management System | Automatic balance, voltage monitor, temperature monitor, DC leakage monitor, etc |
| Cooling Mode | Air cooling |
| Communication Interface | CAN |
| Size(mm) | 2600×1520×825 |
| Weight(kg) | 2500 |
