UHV-2000A HV Hipot PD Test Equipment 2 Channel Automatic Partial Discharge Test System for Transformer

Wuhan UHV Power Technology Co., Ltd.

Hubei,China

Summary

No.1600381949805

$17500.00

INQUIRY

Description Download

Key attributes

customized support

OEM, ODM, OBM, Software reengineering

place of origin

Hubei, China

warranty

1 years

brand name

UHV

model number

JFD-2000A

Product name

Partial Discharge Test System

Measurement channels

A, B 2 channels

Detection sensitivity

0.1PC

Programmable filter setting gear

Low:10,20,40kHz ,High:100,200,300kHz

Gain dynamic range

120dB

Sampling accuracy

8-bit±1/2LSB

PD peak value

0~10000pC

Calibration pulse voltage

10V, 5V, 2V, 1V, 0.5V, 0.2V six-speed adjustable

Calibration capacitor

50pF, 200pF two adjustable

Certification

ISO9001, ISO14001, ISO18001, ISO45001

power

Electronic

Packaging and delivery

Packaging Details

Partial Discharge Test System: Inside packing: bubble board Outside packing: standard wooden box Customer OEM packing also available

Port of dispatch

Shanghai/Wuhan

Selling Units

Single item

Single package size

37X34X70 cm

Single gross weight

98.000 KG

Packaging examples

Supply capacity

Supply Ability

500 sets per Month Partial Discharge Test System

JFD-2000A HV Hipot PD Test Equipment 2 Channel Automatic Partial Discharge Test System For Transformer

Product Description

HT-1200 China Factory Six Phase Secondary Injection Relay Test Set relay tester

JFD-2000A Partial discharge detection system it is the main test item of power equipment insulation, local discharge and other parameters are important indexes to evaluate the quality of power equipment. JFD-2000A partial discharge detection system is a new generation member of successful HTJF series. In addition to the inherited generation product advantages, the products have full program-controlled automatic calibration, automatic synchronization, automatic voltage record, automatic measuring preservation playback function, can be repeated measurements such as discharge rate n, average discharge current I, D square rate such as IEC -270 under various parameters and partial discharge using sine, lattice view shows a variety of ways, a new type of digital filter and interference suppression function, statistical analysis combined with abundant dynamic map, make field interference can be more effectively suppressed, user operation and easy diagnosis more easily. With the continuous development of the software, its functions are also constantly expanded, such as pulse polarity identification and balance circuit mode partial discharge measurement and other functions.

Features

1. Partial discharge detection system pure program control working mode

2. Full Chinese menu prompt

3. Automatic calibration, automatic synchronization, automatic voltage recording, automatic measurement saving and playback

4. Automatically generate test report

5. 2D and 3D partial discharge pattern display

6. Adopt digital window-opening technology, strong anti-interference ability

7. Dual-channel measurement and digital difference technology can simultaneously measure the partial discharge signal of two samples or two measurement points of one sample, which can conveniently analyze the source of partial discharge signal

Structure

No.	Item	Specification	Unit	QTY
1	Power Frequency Non-Partial Discharge Test Transformer	YDQ-10kVA/100kV	PC	1
2	Control Cabinet	TC-10KVA	PC	1
3	Coupling Capacitor	HTCW-100	PC	1
4	Separated Transformer	10KVA	PC	1
5	Protection Resistor	HT-R100KV	PC	1
6	Partial Discharge Detector	JDF-2000	PC	1

Product Paramenters

Measuring channel	A, B 2 channels
Measuring sensitivity	0.1pC
Measuring frequency range	3dB width 10kHz-300kHz
Programmable filter gears setting	Low end:10,20,40kHz , High end:100,200,300 kHz
Gain dynamic range	120dB
Sampling rate	0.1μs/point for each channel
Sampling accuracy	8 bit±1/2LSB
Synchronous frequency	30,100,150,200,250Hz or any Hz
Calibration impulse generator	HTJF-301
Calibration impulse voltage	10V,5V,2V,1V,0.5V,0.2V :six gears available
Calibration capacitor	50pF,200pF :two gears available
Calibration impulse voltage rise time	<60ns, pulse width>20μs
Calibration impulse voltage fall time	>100μs
Calibration phase angle range	0-360
PD peak value	0-1000pC
Working power	AC 220V±10%,50Hz, power<100VA, fuse 0.5A

Company Profile

Wuhan Ultra High Voltage Electric Power Technology CO.,Ltd. (Branches of Wuhan Huatian Electric Power Automation Co.,Ltd.) Established in 2021. we are located in Wuhan East Lake High-Tech Development
Zone, which is also named Wuhan Optical Valley with convenient transportation access.
Wuhan Ultra High Voltage Electric Power is a well-experienced OEM/ODM factory engaged in the research, development, manufacture, sale and service of electric power testing equipment or systems.Including AC Series Resonant Test System, AC/DC/VLF Hipot Test Set, Transformer Tester, Secondary Injection Relay Tester, Cable/Line Tester, Insulation Oil Tester, Circuit Breaker/Switch Tester and SF6 Test Equipment etc.
They are widely used in electric power,energy, transportation,metallurgical,chemical,mining and water conservancy project. We have obtained the ISO 9001 quality system certification, OHSAS 18001:2007 Occupational Health and Safety Management System certification and all products conform to the international CE or Chinese state standards.
Our products are widely exported to all over the world and our service are recognized and highly appreciated by world scale customers, we will always right be here take the customer as first priority and provide you the best solution. Looking forward to building a thrust-worthy and long-term relationship with you.

Hot Products

Packing & Delivery

FAQ

1. Is your company a sales company or a manufacturer?

Wuhan Ultra High Voltage Electric Power Automation CO., LTD. is an industrial and trade enterprise, with its own factory,
self-produced and self-sold. We were founded in 2004 and have Seventeen years of production experience. Our company has reliable production lines, test rooms, QC rooms and R&D centers.

2. When can i get the price ?

We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please call us or send us your email so that we can provide you the details at our first time.

3.What is your terms of delivery ?

We accept EXW, FOB, CFR, CIF ect. You can choose the one which is the most convenient and cost effective for you.

4. How much will be the Shipping cost and time?

This will depend on the size and quality of the goods you purchased and the method of shipping(by sea/ by air/ by Epress) and your designated port or air port. We will be grateful of you can spare us some times to evaluate the cost based on the information provided.

5. Could you please tell me the Warranty Period of your product ?

Our warranty period is one year free and lifelong maintance, and if the product is damaged (if not man-made damage),
in the first year, we will send free parts for replacement or free repairment if you willing to send back the equipment (customer will take the shipment cost).

6.What kind of Certificate can you provide ?

We can provide the CE mark, ISO 9001 quality certificate, the third party calibration certificate(CNAS), factory test report etc.

7.Do you have Technique support to all customers from different countries ?

To be frankly, our technical support is always available and quick response in 12 hours. We are manufacturer of so much on site testing experience and understand how to deal with your problems.
