Approval
TUV Pending
Recognized Component for Canada and U.S. 0.04A~25A
Interrupting Rating
40mA~3.15A: 1500 amperes at 500V DC
100 amperes at 500V AC/DC
100 amperes at 600V AC (UL)
4A~15A: 100 amperes at 600V AC (UL)
100 amperes at 500V AC/DC
16A~25A: 100 amperes at 500V AC/DC
Material
Ceramic body / Nickel Plated Brass Caps
Lead Wire:
Diameter ?0.8mm 12A and less.
Diameter ?1.0mm for rating above 16A
Environmental Specification
Operating Temperature: -55°C to +125°C
