Product Advantage
Delivering up to 1200VA output power with a 20A DC input current, the X1-Micro 2 in 1 sets a high standard in energy conversion efficiency. Featuring two independent MPPT channels, it maximizes solar yield across variable conditions.
Assured Safety
- Built-in industrial grade Wi-Fi module
- Safety protection relay integrated
- IP67 protection class
High Efficiency
- Max. 600VA output power
- Max. 20A DC input current
- Single MPPT for optimal energy harvest
Intelligent Design
- Reactive power control
- Faster installation with plug and play cables and connectors
- Complies with advanced grid support and voltage/frequency ride-through requirements for enhanced stability
- Industrial-grade PLC module for stable data transmission and easier wiring
Flexible Adaptability
- Easy and flexible expansion of system capacity
- Support AC coupling solution
- Support 1-phase microinverter integration into 3-phase power grids*
Product Parameters
X1-Micro 750
PV INPUT
| Commonly used module power per input | 240~470+W |
| MPPT voltage range | 22 ~ 60 V |
| Number of MPP. trackers/strings per MPPT | 2 / 1 |
AC OUTPUT
| Rated AC output power | 750 VA |
EFFICIENCY
| Peak efficiency | 96.50% |
| Nominal MPPT efficiency | 99.90% |
GENERAL
| Ingress protection rating | IP67 |
| Dimensions (W /H / D) | 260x212x40 mm |
| Weight | 4.1 kg |
| Cooling Concept | Natural cooling |
X1-Micro 800
PV INPUT
| Commonly used module power per input | 320~540+W |
| MPPT voltage range | 22 ~ 60 V |
| Number of MPP. trackers/strings per MPPT | 2 / 1 |
AC OUTPUT
| Rated AC output power | 800 VA |
EFFICIENCY
| Peak efficiency | 96.50% |
| Nominal MPPT efficiency | 99.90% |
GENERAL
| Ingress protection rating | IP67 |
| Dimensions (W /H / D) | 260x212x40 mm |
| Weight | 4.1 kg |
| Cooling Concept | Natural cooling |
X1-Micro 900
PV INPUT
| Commonly used module power per input | 360~600+W |
| MPPT voltage range | 22 ~ 60 V |
| Number of MPP. trackers/strings per MPPT | 2 / 1 |
AC OUTPUT
| Rated AC output power | 900 VA |
EFFICIENCY
| Peak efficiency | 96.50% |
| Nominal MPPT efficiency | 99.90% |
GENERAL
| Ingress protection rating | IP67 |
| Dimensions (W /H / D) | 260x212x40 mm |
| Weight | 4.1 kg |
| Cooling Concept | Natural cooling |
X1-Micro 1000
PV INPUT
| Commonly used module power per input | 360~600+W |
| MPPT voltage range | 22 ~ 60 V |
| Number of MPP. trackers/strings per MPPT | 2 / 1 |
AC OUTPUT
| Rated AC output power | 1000 VA |
EFFICIENCY
| Peak efficiency | 96.50% |
| Nominal MPPT efficiency | 99.90% |
GENERAL
| Ingress protection rating | IP67 |
| Dimensions (W /H / D) | 260x212x40 mm |
| Weight | 4.1 kg |
| Cooling Concept | Natural cooling |
X1-Micro 1200
PV INPUT
| Commonly used module power per input | 400~670+W |
| MPPT voltage range | 22 ~ 60 V |
| Number of MPP. trackers/strings per MPPT | 2 / 1 |
AC OUTPUT
| Rated AC output power | 1200 VA |
EFFICIENCY
| Peak efficiency | 96.50% |
| Nominal MPPT efficiency | 99.90% |
GENERAL
| Ingress protection rating | IP67 |
| Dimensions (W /H / D) | 260x212x40 mm |
| Weight | 4.1 kg |
| Cooling Concept | Natural cooling |
